Alternate Text

Customize your product

Faceplate
BOTTOM FACING WITHOUT BLOWER AC01352
BOTTOM FACING WITH BLOWER AC01354
+ €264.00
Total €1,440.00 *
Technical Specifications

Print

EB00033

DESTINATION 1.5-I WOOD INSERT

Fuel type : Dry cordwood
Maximum log length : 48 cm
Size : 848 mm W X 450 mm D X 557/638 mm H
CO at 13% O2 : 0.16 %
* Sales price including all tax. The displayed price do not include freight and installation charges.

  • Description
  • Options and Accessories
  • Specs / Manual

Description

Register your warranty

High resolution images

Options and Accessories

Options

Part number and description
Price
Shipping time

REAR FINISHING PANEL

AC01355

From €84.00 TTC
In stock

Accessories

Adhesives, gaskets and insulation

Part number and description
Price
Shipping time

SILICONE AND 5/8" X 8' BLACK DOOR GASKET KIT

AC06500

From €12.00 TTC
In stock

Paint

Part number and description
Price
Shipping time

METALLIC BLACK STOVE PAINT - 342 g (12oz) AEROSOL

AC05959

From €15.00 TTC
In stock

Specs / Manual

Appliance performance (1)

Fuel type : Dry cordwood
Heated volume (m³) : 115 - 390
Firebox nominal volume (m³) : 0.043
Eciency : 77.4 %
CO at 13% O2 : 0.16 %
Nominal heat output : 6 kW
Burn time (hours) : 5 - 6

(1) Values are as measured per test method, except for the recommended heating area, firebox volume, maximum burn time and maximum heat output.

General features

Maximum log length 48 cm
Diameter of smoke pipe outlet 150 mm
Baffle type C-Cast
Shipping Weight 145 kg
Door type Single, glass with steel frame
Glass type Ceramic glass
Glass surface – dimensions (Width X Height) 483 mm x 200 mm
Overall dimension (Height) 557/638 mm
Overall dimension (Width) 848 mm
Overall dimension (Depth) 450 mm
Door opening – dimension (Height) 192 mm
Door opening - dimension (Width) 483 mm
Firebox – dimension (Height) 256 mm
Firebox – dimension (Width) 521 mm
Firebox – dimension (Depth) 324 mm
Firebox thickness – Outline 5 mm
Thickness – Top 5 mm
Minimum fireplace opening (height) 521 mm (600 mm-ventilateur)
Minimum fireplace opening (Width) 737 mm
Minimum fireplace opening (depth) 371 mm
Minimum clearances to combustibles*
Clearance – combustible top mantle to unit 343 mm
Clearance – combustible side wall to unit 635 mm
Clearance – top shelf to unit 343 mm

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).

Support and parts

Need a replacement part for your appliance?

We have everything you need! Buy it online or from your local dealer.

Find a replacement part for this product
